Dinstar UC2000-VF GSM VoIP Gateway Oman
Dinstar UC2000-VF Oman is a robust, high-performance 16-channel GSM/3G/4G VoIP Gateway engineered with a durable 1U, field-tested hardware framework that guarantees strong, reliable, and continuous connectivity between mobile networks and VoIP infrastructures, ensuring uninterrupted voice calling and efficient SMS transmission in demanding environments. With its integrated GSM/WCDMA/LTE modules, comprehensive SIP protocol support, and wide compatibility with major VoIP platforms, it allows smooth deployment, simplified configuration, and hassle-free operation across varied telephony setups. This advanced gateway is particularly suitable for enterprises, multi-branch organizations, call termination providers, and businesses working in areas where conventional landline services are limited, unstable, or unavailable, including remote, rural, and geographically challenging locations. By helping reduce communication expenses, optimize network resources, and streamline administration tasks, it enhances overall operational efficiency and boosts productivity. Additionally, the UC2000-VF can operate independently as a standalone gateway or be seamlessly integrated with Dinstar SIMBank and SIMCloud systems, enabling centralized, scalable, and remotely managed SIM card operations for flexible, modern, and future-ready communication deployments.
Features
16-channel VoIP GSM/3G/4G Gateway
- GSM/WCDMA/LTE support
- Voice over LTE (VoLTE)
- Hot Swappable SIM Cards
- Compatible with mainstream VoIP platform
- Mobility Extension, never miss a call
- SMS sending & receiving, SMS API
- Credit Limit management
- Auto CLIP
Applications
- Mobile connectivity for SME IP phone system
- Mobile trunking for Multi-site offices
- GSM/3G as voice backup trunks
- Call termination for service providers
- Land-line replacement for rural area
- Bulk SMS service
- Call Center / Contact Center Solution
Easy Management
- Intuitive Web interface
- Advanced Debug tools
- Remote SIMs management with Dinstar SIMBank & SIMCloud
- Configuration Backup & Restore
Technical Highlights
- 8/16 SIM slot, 8/16 antennas
- Signaling & RTP Encryption
- Built-in antennas combiner (Optional)
- SMPP for SMS
- GSM: 850/900/1800/1900Mhz
- HTTP API for SMS
- WCDMA: 900/2100Mhz or 850/1900Mhz
- Polarity Reversal
- LTE: Multiple frequency choices for different countries
- PIN Management
- SIP v2.0, RFC3261
- SMS/USSD
- Codecs: G.711A/U , G.723.1, G.729AB
- SMS to Email, Email to SMS
- Echo Cancellation
- Call Waiting/Call Back
- DTMF: RFC2833, SIP Info
- Call Forward
- Programmable Gain Control
- GSM Audio Coding: HR, FR,EFR, AMR_FR,AMR_HR
- Mobile to VoIP, VoIP to Mobile
- HTTPS/HTTP Web Configuration
- SIP Trunk and Trunk Group
- Configure Backup/Restore
- Port and Port Group
- Firmware Upgrade by HTTP/TFTP
- Caller/Called Number Manipulation
- CDR(10000 Lines Storage Locally)
- SIP Codes Mapping
- Syslog/Filelog
- White/Black List
- Traffic statistics: TCP,UDP,RTP
- PSTN/VoIP Hotline
- VoIP Call Statistics
- Abnormal Call Monitor
- PSTN Call statistics: ASR,ACD,PDD
- Call Minutes Limitation
- IVR Customization
- Balance Check
- Auto Provisioning
- Random Call Interval
- SIP/RTP/PCM Capture
- Auto CLIP
- Work with Dinstar SIMCloud/SIMBank (Optional)
