Flyingvoice FIP11CP Oman



Flyingvoice FIP11CP Oman

The Flyingvoice FIP11CP Oman Wireless SIP Phone offers users distraction-free communication courtesy of the inbuilt industry-leading Acoustic Echo Cancellation Technology that delivers superior High Definition sound quality devoid of extraneous noises. This makes it possible to enjoy fluent audible phone conversations.

Description

FlyingVoice FIP11CP Wireless SIP Phone Oman

Save yourself from delays and other inconveniences such as high costs by using the premium Flyingvoice FIP11CP Oman Wireless SIP Phone which is easy to use and simple to deploy. The 2.4 inch colour display comes with a new LCD design, providing you with rich visual experience. The programmable keys offer extensive productivity-enhancing features such as PoE, HD voice, and easy access to various WiFi options. The FIP11CP supports OPUS and IEEE 802.3af Power over Ethernet (PoE) while offering a 10/100Mbps dual-port switch with a 300Mbps 2.4GHz Wi-Fi module. The Flyingvoice FIP11CP supports 3 SIP accounts as well as 3 – way conferencing, allowing you to create and join group calls. Grow your business to higher limits by facilitating seamless communication courtesy of the Flyingvoice FIP10P classic Wireless SIP phone that has been diligently designed to serve business entities.

FEATURES

SIP CONVENIENCE

The Server-Initiated Application (SIP) is incorporated for users to plug and play the phone without the need for configurations. Once the phone is connected to the network and powered on, initialization commences automatically, after which the phone is up and ready for use. Furthermore, the Flyingvoice FIP11CP Wireless SIP phone can not only be configured via a user interface, it also accepts SIP NOTIFY messages from SIP proxy servers, which gives it an ability to act as a web server.

You can therefore easily connect your FlyingVoice FIP11CP Wireless SIP Phone to your IP PBX System or direct to a VoIP service provider in order to enjoy seamless conference calls. The Flyingvoice FIP11CP Wireless SIP phone is based on SIP v1(RFC2543) and SIP v2 (RFC 3261) and works perfectly with most of the SIP platforms that currently exist in the market.

EASY OPERATION

The FlyingVoice FIP11CP Wireless SIP Phone is designed to ease call control on the display by using soft keys for daily functions such as transfer, conference and forwarding. You can also access the corporate directory quickly via the soft keys. The user can use the application keys such as the Phone key, Main menu, Contacts and Recents to navigate through the phone and display a list of options including features, network information, administration and many others.

FLEXIBILITY FOR PRODUCTIVITY

The Flyingvoice FIP11CP Wireless SIP Phone pushes versatility to a new high, thanks to its ability to complement already existing fixtures for enhanced web and video

conferencing, as well as other communication needs. This makes it easy to integrate seamlessly into any office setup without disorienting earlier structures and work ethic. Furthermore, the device is easy to redeploy as the business grows and needs to transform.

MANAGEMENT PLATFORM

The Flyingvoice FIP11CP Wireless SIP Phone delivers convenience, reliability and seamless integration through the Flyingvoice Device Management Platform via an installed unified firmware. The platform is also used to troubleshoot and solve some of the common complexities that sometimes come during provisioning, call management, and quality control. It also enhances user experience and adoption, making it easy to consolidate clients under one platform. This not only makes the device easy to deploy and maintain, but also gives you the ability to keep it at par with new and advanced firmware updates, thus a reduction in upgrade, maintenance and operational costs. The Flyingvoice FIP11CP Wireless SIP Phone is, thus, a perfect solution regardless of the variations in your company’s needs.

SUPERIOR HIGH DEFINITION AUDIO

The Flyingvoice FIP11CP Wireless SIP Phone offers users distraction-free communication courtesy of the inbuilt industry-leading Acoustic Echo Cancellation Technology that delivers superior High Definition sound quality devoid of extraneous noises. This makes it possible to enjoy fluent audible phone conversations.

CONFERENCE GUIDE

This advanced feature of the Flyingvoice FIP11CP Wireless SIP Phone helps the user to easily set up group calls with a single click of a button. The hi-tech device allows for 3 – way group calls. Its phone book offers you an allowance of a maximum of one thousand (1,000) entries per profile. You can simply create a meeting or join one seamlessly while using your device.

INTERNET WIRELESS CONNECTION

The Flyingvoice FIP11CP Wireless SIP Phone supports Wi-Fi® Wireless connections from a speed of 2.4GHZ. This enhanced feature offers you unparalleled convenience when it comes to content sharing and audio streaming.

HIGH SECURITY & COMPATIBILITY

Make all your conversations secure by using the Flyingvoice FIP11CP Oman Wireless SIP Phone which uses security algorithms such as configuration files that utilize AES, SRTP and TLS call encryption. The Flyingvoice FIP11CP Wireless SIP Phone is compatible with SIP – based PBX platforms such as Asterisk, BroadSoft and 3CX.

THE MESSAGE WAITING INDICATOR

This feature comes in the form of notification to alert you of a new voicemail message. The audible Message Waiting Indicator hinges on a ‘stutter dial tone’ to notify the user when a message is waiting to be retrieved, whereas a visual Message Waiting Indicator triggers a light or notice on the phone display, ensuring that you never miss out on important phone calls.

CALL TRANSFER

This advanced feature of the Flyingvoice FIP11CP Oman Wireless SIP Phone allows the user to relocate an inbound call to another phone or messaging system by using a dedicated call transfer button on the phone, or software that has been configured for use on the Wireless Phone.

CALL WAITING

You can hear another incoming call when you are already on an active phone call (beep). With the Flyingvoice FIP11CP Wireless SIP Phone, you can also turn off call waiting so that incoming calls are directly sent to voicemail during moments you are active on another Phone call.

CALL HOLDING

You can easily place an active phone call on hold in order to make or pick another incoming call using the premium Flyingvoice FIP11CP Wireless SIP Phone.

Why the Flyingvoice FIP11CP Wireless SIP Phone?

  • The FIP11CP comes with a simple design yet ergonomic design that is easy to use. Prompts guide you through a simple installation process making it easy to make that first call.
  • The FIP11CP provides excellent voice quality. We have created high-definition sound quality solutions for handset and hands-free scenarios, even in a noisy environment.
  • Whether in your office or conference room, say goodbye to complex deployments, connect with people the way you like. FIP11CP supports dual 10/100 Mbps ports, PoE and a built-in 2.4G Wi-Fi connection (300Mbps).
  • All conversations are secure. We make use of security algorithms such as configuration files utilising AES, SRTP and TLS call encryption. The FIP1X series SIP phones are compatible with SIP-based PBX platforms such as Asterisk, Broadsoft and 3CX, to name but a few.

FlyingVoice FIP11CP Wireless SIP Phone Specifications

HARDWARE SPECIFICATIONS

Interfaces :

  • 2 x RJ-45 ports (Ethernet 10/100 Base-T)
  • 1 x RJ9 Headset Jack
  • 11n 2T2R (speeds of up to 300Mbps)

Display & Indicators :

  • 320*240 2.4″ Backlit colour screen
  • LED for call and message waiting indication
  • Dual-colour (red/green) illuminated LEDs for line status information

Phone Keys :

  • 4 Soft Keys
  • 7 Feature Keys
  • 5 Navigation Keys
  • 12 Dialling buttons (0~9, *, #)

Power Supply :

  • AC/DC Adapter
  • * AC Input : 100~240V, 50~60Hz
  • * DC Output : 5V, 1A
  • Power consumption (PSU) : 1,5 – 3,5W
  • Power consumption (PoE) : 1,9 – 4,5W

Dimensions :

  • 190mm(L)*188,5mm(W)*173mm(H)*41.55m(T)

Audio Features :

  • HD Voice : HD handset, HD speaker
  • CODECs : OPUS, iLBC, G.711 (A/μ), G.722 (HD), G.723.1, G.729AB
  • DTMF : In-band, RFC 2833 and SIP info
  • Full-duplex hands-free speakerphone
  • VAD, CNG, AEC, PLC, AJB, AGC

Phone Features :

  • 3 SIP accounts
  • Call hold, mute, DND, redial, auto answer
  • One-touch speed dial, hotline, SMS
  • Call forward, call waiting, call transfer (attended/blind)
  • Paging, intercom
  • 3-Way conferencing
  • Direct IP call without SIP proxy
  • Set date time manually or automatically
  • Dial rule
  • IP conflict detection
  • 4 GHz Wi-Fi

Directory :

  • Phone book (1,000 records)
  • Black list
  • XML/LDAP remote phonebook
  • Phonebook search/import/export
  • Call history : dialed/received/missed (60 records)

IP PBX Features :

  • Busy Lamp Fields (BLF)
  • Anonymous call, anonymous call rejection
  • Voicemail, call park, call pickup
  • Message waiting indicator (MWI)

Feature Keys :

  • 3 Line keys
  • 7 feature keys : message, headset, hold, mute, transfer, redial, hands-free speakerphone
  • 4 Soft Keys
  • 5 Navigation Keys
  • Volume+/-

Display & Indicators :

  • Intuitive user interface with icons and soft keys
  • Multilingual user interface
  • Caller ID with name and number
  • Power saving feature

Network & Security

  • SIP v1 (RFC2543), v2 (RFC3261)
  • Call server redundancy supported
  • NAT Traversal By STUN
  • Proxy mode and peer-to-peer SIP link mode
  • IP assignment : Static IP and DHCP
  • HTTP/HTTPS web server
  • Time and date synchronization using SNTP
  • SDP (RFC 2327) ,UDP/TCP
  • Multi-VLAN, DSCP and 802.1p QoS
  • SRTP
  • TLS
  • HTTPS certificate manager
  • AES encryption for configuration files
  • Digest authentication
  • VPN:PPTP, L2TP, OpenVPN
  • IPv4 /IPv6 , Dual stack IPv4/IPv6
  • RTP/RTCP (RFC 1889, RFC 1890)
  • ARP/RARP (RFC 826/903)
  • 1Q VLAN/802.1p/DSCP
  • SNMPv2
  • LLDP/CDP/DHCP VLAN

Management

  • Configuration : browser/phone/auto-provision
  • TFTP/HTTP/HTTPS for Auto Provisioning
  • TR069 (TR104/TR106)
  • Reset to factory, reboot
  • Package tracing export, system log
  • DNS/DNS SRV (RFC 1706, RFC 2782)
  • NAPTR for SIP URI lookup (RFC 2915)
  • DHCP server and DHCP client

Operating Conditions :

  • Operating Temperature : 0~50 Degree C
  • Storage Temperature : -25~ 85 Degree C
  • Relative Humidity : 10%~90% Non-condensing

PACKAGE CONTENTS

  • Flyingvoice FIP11CP Wireless SIP Phone
  • Handset with handset cord
  • Ethernet cable
  • Stand
  • Quick start guide
  • Power adapter (Optional)
