Tplink CPE210 Oman



Tplink CPE210 Oman

The enclosure of the Tplink CPE210 Oman is composed of outdoor ASA stabilized plastic and carries the IPX5 waterproof certification. Underneath the sturdy shell you will find one Fast Ethernet Passive PoE input eliminating the need for an additional PoE adapter.

Category:

Description

Tplink CPE210 Outdoor Radio Oman

Whether using this device as a point to multi-point link or as an access point, the Tplink CPE210 Oman 2.4 GHz N-300 9 dBi Outdoor Customer-Premises Equipment from TP-Link is capable of enhancing network performance and coverage. This CPE features a weatherproof enclosure complete with 15 KV ESD protection and 6,000 V lightning protection allowing it to withstand some of the harshest weather conditions.

The enclosure of the Tplink CPE210 Oman is composed of outdoor ASA stabilized plastic and carries the IPX5 waterproof certification. Underneath the sturdy shell you will find one Fast Ethernet Passive PoE input eliminating the need for an additional PoE adapter. You will also find one grounding terminal for added protection against lightning strikes.

Once installed, you can take advantage of IEEE 802.11b/g/n networking standards to connect nearly any Wi-Fi enabled device to the Internet. The Tplink CPE210 Oman operates on the 2.4 GHz routing frequency supporting a maximum data transfer rate of up to 300 Mbps with a transmit power of up to 27 dBm. Configure the CPE to suit nearly any networking need with support for AP, client, bridge, repeater, AP router mode, and AP client (WISP client) operation modes.

Features

  • Tplink CPE210 Oman has built-in 9 dBi 2×2 dual-polarized directional MIMO antenna
  • Adjustable transmission power from 0 to 27 dBm / 500 mw
  • System-level optimizations for more than 9 mi+ (15 km+) long range wireless transmission
  • TP-LINK Pharos MAXtream (Time-Division-Multiple-Access) technology improves product throughput, capacity and latency performance, ideal for PTMP applications
  • Tplink CPE210 Oman is integrated with a centralized Management System – Pharos Control
  • AP / Client / Repeater / Bridge / AP Router / AP Client Router (WISP) operation modes
  • Passive PoE Adapter supports up to 200 feet (60 meter) Power over Ethernet deployment and allows the device to be reset remotely

Technical Specs

Wireless
Wireless Frequency Bands 2.4 GHz Single-Band
Number of Antennas 1
MU-MIMO Support 2 x 2
WLAN Mode Wi-Fi 4 (802.11n)
Sensitivity -76 to -96 dBm
Antenna Gain 9 dBi
Transmit Power 26 to 27 dBm
Supported Protocols
  • MAC Filtering
  • SSID
Antenna Placement Internal
Performance
Throughput 300 Mb/s Total
2.4 GHz : 300 Mb/s
Interface
Ports 1 x 10/100 Mb/s Ethernet (RJ45) PoE (Type 1)
USB Sharing Support No
Security
Guest Network Support No
Wireless Security WEP, WPA, WPA2
VPN Protocol None
Firewall Support None
Hardware
RAM 64 MB
Storage Capacity 8 MB
Supported IEEE Standards 802.11b, 802.11g, 802.11n
Electrical
DC Input Power 16 to 27 VDC
Power Consumption 10.5 W
Environmental
Operating Temperature -22 to 158°F / -30 to 70°C
Storage Temperature -40 to 158°F / -40 to 70°C
Operating Humidity 10 to 90%
Storage Humidity 5 to 95%
General
IP Rating IPX5
Certifications FCC
*as per Manufacturer
Dimensions 8.8 x 3.1 x 2.4″ / 224 x 79 x 60 mm
Packaging Info
Package Weight 1.67 lb
Box Dimensions (LxWxH) 10.7 x 5.3 x 4.15″
