Tplink RE305 Oman



Tplink RE305 Oman

Tplink RE305 Oman is more than a wireless range extender. Simply plug the Ethernet cable into its Ethernet port to easily turn your wired internet connection into a dual-band wireless access point.

Description

Tplink RE305 Range Extender Oman

Tplink RE305 Oman connects to your router wirelessly, strengthening and expanding its signal into areas it can’t on its own. The device also reduces signal interference to ensure reliable Wi-Fi coverage throughout your home or office.

The Tplink RE305 Oman lets you keep more devices connected at the same time with its 2.4GHz 300Mbps and 5GHz 867Mbps dual bands. Use the 2.4GHz band to send email and browse the web, and the 5GHz band for gaming and HD streaming. An Intelligent Signal light helps you quickly find the best location to install the RE305.

Tplink RE305 Oman is more than a wireless range extender. Simply plug the Ethernet cable into its Ethernet port to easily turn your wired internet connection into a dual-band wireless access point.

The Tplink RE305 Oman works with all Wi-Fi routers. You can use TP-Link’s free Tether app to set up the range extender from any Android or iOS device in minutes. This feature-rich phone app allows you to enjoy not only hassle-free installation but also access to advanced network management, all at your fingertips.

Quick Features

  • Brings Wi-Fi dead zone to life with strong Wi-Fi expansion at a combined speed of up to 1.2Gbps
  • Operates over both the 2.4GHz band(300Mbps) and 5GHz band(867Mbps) for more stable wireless experience
  • Intelligent signal light helps to fi­nd the best location for optimal Wi-Fi coverage by showing the signal strength
  • Tplink RE305 Oman works with any Wi-Fi router or wireless access point

Technical Specs

WIRELESS
Working Modes Range Extender/Access Point
HARDWARE FEATURES
Plug Type EU, UK, US
Ports 1 x 10/100Mbps Ethernet Port (RJ45)
Button WPS Button, Reset Button
Input Power 100-240V~50/60Hz
Power Consumption 7.3W(max power consumption)
Dimensions ( W x D x H ) 3.1 x 3.0 x 3.0 in. (80 x 78 x 77mm)
Antenna 2 External Antennas
WIRELESS FEATURES
Wireless Standards IEEE 802.11a/n/ac 5GHz, IEEE 802.11b/g/n 2.4GHz
Frequency 2.4GHz and 5GHz
Signal Rate 300Mbps at 2.4GHz, 867Mbps at 5GHz
Reception Sensitivity 5GHz:

  • 11a 6Mbps : -91dBm
  • 11a 54Mbps : -74dBm
  • 11ac HT20 mcs8 : -68dBm
  • 11ac HT40 mcs9 : -63dBm
  • 11ac HT80 mcs9 : -59dBm2.4GHz
  • 11g 54Mbps : -79dBm
  • 11n HT20 mcs7 : -77dBm
  • 11n HT40 mcs7 : -74dBm
Wireless Functions
  • Enable/Disable Wireless Radio
  • DFS (the latest firmware and hardware version is required)
  • Access Control
  • LED Control
  • Power Schedule
  • Wi-Fi Coverage
Wireless Security
  • 64/128-bit WEP
  • WPA-PSK / WPA2-PSK
Transmission Power 2.4G<17dBm, 5G<17dBm
OTHERS
Certification CE, FCC, RoHS
Package Contents
  • AC1200 Wi-Fi Range Extender RE305
  • Quick Installation Guide
Box Dimensions (W X D X H) 6.15 x 4 x 3.7 in. (156.5 x 101.5 x 95mm)
System Requirements Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7, 8, 10, Mac OS, NetWare, UNIX or Linux.
Environment
  • Operating Temperature : 0°C~40°C (32°F~104°F)
  • Storage Temperature : -40°C~70°C (-40°F~158°F)
  • Operating Humidity : 10%~90% non-condensing
  • Storage Humidity : 5%~90% non-condensing
