Tplink TL-PA8010P KIT Oman



Tplink TL-PA8010P KIT Oman

Distribute your network through the electrical wiring of your home or office with the Tplink TL-PA8010P KIT Oman HomePlug-AV1200 Gigabit Passthrough Powerline Starter Kit from TP-Link.

Description

Tplink TL-PA8010P KIT Powerline Adapter Oman

With one Gigabit Ethernet port, Tplink TL-PA8010P KIT Oman allows users to connect a bandwidth intensive device to the Internet at high speeds and ensures the smooth transmission of Ultra HD video streaming. This makes the TL-PA8010P KIT the perfect home entertainment companion.

Distribute your network through the electrical wiring of your home or office with the Tplink TL-PA8010P KIT Oman HomePlug-AV1200 Gigabit Passthrough Powerline Starter Kit from TP-Link. This powerline adapter kit consists of two adapters each featuring a single outlet and one Gigabit Ethernet port. With support for data transfer rates of up to 1200 Mbps you can easily transfer large files, stream HD content, and more at distances of up to 984′ (300 m). Pairing the two adapters is easy with integrated pairing buttons while 128-bit AES encryption keeps your network connection secure.

Features

  • HomePlug AV2 standard compliant, high-speed data transfer rate of up to 1200 Mbps, ideal for Ultra HD streaming and online gaming
  • Line-Neutral/Line-Ground 2×2 MIMO with beamforming ensures fast and stable connection
  • Gigabit Ethernet port allows your TVs, game consoles, or PCs to connect to the Internet
  • Embedded power socket makes power accessible to other devices
  • No new wires, use existing electrical wiring
  • Up to 984′ (300 m) range over the household power circuit
  • Plug and play, no configuration required
  • 128-bit AES encryption ensures that the network is safe simply by pressing a button on paired devices
  • Power saving mode reduces power consumption by up to 85%
  • Tplink TL-PA8010P KIT Oman is compatible with all AV1200, AV1000, AV600, AV500 & AV200 Powerline adapters

Specifications

Number of Ethernet Ports 1
Ethernet Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 1901
Ethernet Speed 10/100/1000 Mb/s
Powerline Technology HomePlug AV
Modulation Technology OFDM
Maximum Networking Distance 984′ / 300 m
Plug Type US (3-Pin)
AC Pass-Through Yes
Encryption 128-Bit AES (-Based)
Standby Power Consumption 0.5 W
Current 16 A
Operating System Support macOS/OS X, Linux, Windows
Operating Temperature 32 to 104°F / 0 to 40°C
Operating Humidity 10 to 90%
Storage Temperature -40 to 158°F / -40 to 70°C
Storage Humidity 5 to 90%
Dimensions (W x H x D) 5.2 x 2.8 x 1.7″ / 132.1 x 71 x 43.2 mm
Packaging Info
Package Weight 1.86 lb
Box Dimensions (LxWxH) 9.4 x 7.65 x 3.9″
HARDWARE FEATURES
Plug Type EU, UK
Standards and Protocols HomePlug AV2, HomePlug AV, IEEE1901, IEEE802.3, IEEE802.3u, IEEE802.3ab
Interface 1 * Gigabit Ethernet Port, Power Socket
Button Pair Button
Power Consumption
  • Maximum : 6W (220V/50Hz)
  • Typical : 6W (220V/50Hz)
  • Standby : 0.5W (220V/50Hz)
LED Indicator PWR, PLC, ETH
Dimensions ( W x D x H ) 5.2×2.8×1.7 in. (131×72×42 mm)
Range 300 Meters over electrical circuit
Power Output to Integrated Socket 16 A
SOFTWARE FEATURES
Modulation Technology OFDM (PLC)
Encryption Powerline Security :
128-bit AES
OTHERS
Certification CE, RoHS
Package Contents
  • Powerline Ethernet Adapter
  • 6.5 ft. (2 m) Ethernet cable (RJ45)
  • Resource CD
  • Quick Installation Guide
System Requirements Windows 2000/XP/2003/Vista, Windows 10/7/8, Mac, Linux
Environment
  • Operating Temperature : 0°C~40°C (32°F ~104°F)
  • Storage Temperature : -40°C~70°C (-40°F ~158°F)
  • Operating Humidity : 10%~90% non-condensing
  • Storage Humidity : 5%~90% non-condensing
