Tplink TL-SG2008 Oman



Tplink TL-SG2008 Oman

With a variety of Layer 2 network features, the Tplink TL-SG2008 Oman 8-Port Gigabit Smart Switch from TP-Link gives network administrators complete control over a variety of network functions.

Description

Tplink TL-SG2008 Network Switch Oman

With a variety of Layer 2 network features, the Tplink TL-SG2008 Oman 8-Port Gigabit Smart Switch from TP-Link gives network administrators complete control over a variety of network functions. With loop back detection, cable diagnostics and IGMP snooping, this switch is capable of ensuring traffic is managed efficiently and effectively. The eight Gigabit Ethernet ports offer a fast, reliable wired connection while the advanced QoS (Quality of Service) feature set makes it simple to designate priority traffic to ensure bandwidth intensive tasks have the necessary network resources.

Features

Layer 2 Features
  • Static Link Aggregation/ Link Aggregation Control Protocol (LACP)
  • Up to 512 VLANs simultaneously(out of 4K VLAN IDs)
  • STP/RSTP/MSTP
  • IGMP Snooping
Quality of Service
  • 4 priority queues
  • Support IEEE 802.1P
  • DSCP QoS
  • Rate limit feature
Security Strategies
  • Access Control List (L2~L4 ACL)
  • Port Security
  • Storm Control
  • SSL and SSH encryptions
Management
  • Web-based GUI
  • Command Line Interface (Telnet)
  • SNMP v1/v2c/v3
  • RMON (1, 2, 3, 9 group)

Technical Specs

Interfaces
Ports 8 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45)
Protocols
Supported Protocols
  • Auto-MDIX/MDI
  • IGMP Snooping
  • Link Aggregation
Queuing Strict Priority, Weighted Round Robin (WRR)
Jumbo Frames Support 9,216 Bytes
MAC Address Table Size 8K
VLAN Groups 512
VLAN IDs 4000
Security
Security Features Storm Control
Standards
Supported IEEE Standards 802.1d, 802.1p, 802.1q, 802.1s, 802.1w, 802.3ab, 802.3ad, 802.3i, 802.3u, 802.3x
Performance
Forwarding Rate 11.9 Mpps
Switching Bandwidth 16 Gb/s
Priority Queues 4
Computer
OS Compatibility
  • Windows XP or Later
  • macOS
  • Linux
  • UNIX
Electrical
Power Draw 6.42 W (Active)
AC Input Power 100 to 240 VAC, 50 / 60 Hz
Environmental
Operating Temperature 32 to 104°F / 0 to 40°C
Operating Humidity 10 to 90%
Storage Temperature -40 to 158°F / -40 to 70°C
Storage Humidity 5 to 90%
Certifications RoHS, as per Manufacturer
General
Cooling System Passive
Dimensions 8.2 x 4.9 x 1″ / 20.9 x 12.6 x 2.6 cm
Packaging Info
Package Weight 2.1 lb
Box Dimensions (LxWxH) 11.024 x 8.898 x 2.677″
