Tplink TL-SG3210XHPM2 Oman



Tplink TL-SG3210XHPM2 Oman

Featuring 8× 2.5 Gbps PoE+ ports, the Tplink TL-SG3210XHPM2 Oman switch is capable of future network expansion and deployment, providing sufficient bandwidth for incoming WiFi 6 APs.

Description

Tplink TL-SG3210XHPM2 Network Switch Oman

Featuring 8× 2.5 Gbps PoE+ ports, the Tplink TL-SG3210XHPM2 Oman switch is capable of future network expansion and deployment, providing sufficient bandwidth for incoming WiFi 6 APs. Designed to use a single Ethernet cable for both data and power transmission, it supports up to 240 W total PoE power budget* and flexible installation to fit in various application scenarios.

2× 10 Gbps SFP+ slots provide non-blocking switching performance and ultra-low latency, so reliable and lightning-fast connections to servers and other switches are easily built.

Features

Unlock the Full Potential of WiFi 6 with Multi-Gigabit PoE+ Ports

Featuring 8× 2.5 Gbps PoE+ ports, the Tplink TL-SG3210XHPM2 Oman switch is capable of future network expansion and deployment, providing sufficient bandwidth for incoming WiFi 6 APs. Designed to use a single Ethernet cable for both data and power transmission, it supports up to 240 W total PoE power budget and flexible installation to fit in various application scenarios.

Enterprise Switch with 10G Uplink

2× 10 Gbps SFP+ slots provide non-blocking switching performance and ultra-low latency, so reliable and lightning-fast connections to servers and other switches are easily built.

Software-Defined Networking (SDN) with Cloud Access

Omada’s Software-Defined Networking (SDN) platform on the Tplink TL-SG3210XHPM2 Oman integrates network devices, including access points, switches, and gateways, providing 100% centralized cloud management. Omada creates a highly scalable network—all controlled from a single interface. Seamless wireless and wired connections are provided, ideal for use in hospitality, education, retail, offices, and more.

Advanced L3 Features

An abundance of L2+ and L3 features are supported to help build a highly scalable and robust network, providing a reliable and efficient solution for enterprises, campuses, and ISPs.

Secure Networking

Security features of the Tplink TL-SG3210XHPM2 Oman include IP-MAC-Port-VID Binding, Port Security, Storm Control and DHCP Snooping to defend against a range of network threats. An integrated list of common DoS attacks is available, making it easier than ever to prevent them. In addition, the Access Control Lists (ACL, L2 to L4) feature restricts access to sensitive network resources by denying packets based on source and destination MAC address, IP address, TCP/UDP ports, or VLAN ID. Users’ network access can be controlled via 802.1X authentication, which works with a RADIUS/Tacacs+ server to grant access only when valid user credentials are provided.

Enterprise Level Features

A complete lineup of L2+ features are supported, including 802.1Q VLAN, Port Mirroring, STP/RSTP/MSTP, Link Aggregation Control Protocol, and 802.3x Flow Control. Advanced IGMP Snooping ensures the switch intelligently forwards multicast streams to only the appropriate subscribers, cutting out unnecessary traffic, while IGMP throttling & filtering restrict each subscriber on a port level to prevent unauthorized multicast access. Static Routing is a simple way of segmenting the network and internally routs traffic through the switch for improved efficiency.

Advanced QoS

Voice and video traffic can be prioritized based on IP address, MAC address, TCP port number, UDP port number, and more. With QoS (Quality of Service), voice and video services remain smooth, even when bandwidth is in short supply.

ISP Features

sFlow, QinQ, L2PT PPPoE ID Insertion, and IGMP authentication features are provided, developed with service providers in mind. 802.3ah OAM and Device Link Detection Protocol (DLDP) offer easy monitoring and troubleshooting of Ethernet links.

IPv6 Support

IPv6 functions of the Tplink TL-SG3210XHPM2 Oman such as Dual IPv4/IPv6 Stack, MLD Snooping, IPv6 ACL, DHCPv6 Snooping, IPv6 Interface, Path Maximum Transmission Unit (PMTU) Discovery, and IPv6 Neighbor Discover guarantee your network is ready for the Next Generation Network (NGN) without upgrading your hardware.

Technical Specs

Edition JetStream
Form Factor Rackmount
Total Network Ports
  • 8 x 10/100/1000 (Gigabit) RJ-45
  • 8 x 100/1000/2.5G BASE-T RJ45
  • 2 x SFP+ 1000/10G (Dedicated)
PoE Support Type PoE+
No. of Ports Providing PoE
  • 8 x 10/100/1000 (Gigabit) RJ-45
  • 8 x 100/1000/2.5G BASE-T RJ45
Other Non-Network Ports
  • 1 x Console (RJ45)
  • 1 x Micro-USB Console
Switching Capacity 80 Gbps
Non-Blocking Throughput
Forwarding Rate 59.52 Mpps
MAC Address Table Size 16K Entries
Network Capacity
Built-in Flash Memory
RAM Memory
Network Protocols
  • IEEE 802.1d
  • IEEE 802.1p
  • IEEE 802.1Q
  • IEEE 802.1s
  • IEEE 802.1w
  • IEEE 802.1x
  • IEEE 802.3ab
  • IEEE 802.3ad
  • IEEE 802.3af
  • IEEE 802.3at
  • IEEE 802.3az
  • IEEE 802.3i
  • IEEE 802.3u
  • IEEE 802.3x
  • IEEE 802.3z
Acoustic Noise
Max. Power Consumption 291.49 W
Max. PoE Wattage per Port
Mean Time Between Failures (MTBF)
Power Supply Internal AC Power Supply
Material
Includes Rack Mounting Brackets
Dimensions (WxHxD) 440 x 44 x 180 mm
Weight
Additional Information
Scan Code LN114585
Model Number TL-SG3210XHP-M2
GTIN 6935364030803
