Tplink TL-SG3428X Oman



Tplink TL-SG3428X Oman

The Tplink TL-SG3428X Oman can be integrated into the Omada Software Defined Networking (SDN) platform along with the Omada Access Points and gateways, allowing for 100% centralized cloud management of the whole network from different sites to be controlled from a single user interface.

Description

Tplink TL-SG3428X Network Switch Oman

The Tplink TL-SG3428X Oman helps you expand your network coverage using its 24 gigabit Ethernet ports and 4ÿ 10 Gbps SFP+ uplink ports. It is a fully managed switch that is seamlessly integrated into Omada SDN system, and is capable of being centrally managed via web UI or Omada app. Ideal for small, medium, and large enterprise networks, it meets and surpasses the needs for high-speed, reliable, and safe enterprise networks.

The Tplink TL-SG3428X Oman by TP-Link is a 24 Port managed switch with 4 x 10G SFP+ interfaces for lightning-fast connections to servers and other switches, with backwards compatibility with 1G products allowing for long-term usability through your network upgrades.

The Tplink TL-SG3428X Oman Managed switch is an ideal option for enterprise, campus or ISP networks, with high performance powerful L2 and L2+ features such as enterprise-level QoS, Static Routing, Advanced security strategies and a bundle of ISP features. An easy-to-use web management interface along with CLI, SNMP and Dual Image also allows for a quick setup and configuration.

The Tplink TL-SG3428X Oman can be integrated into the Omada Software Defined Networking (SDN) platform along with the Omada Access Points and gateways, allowing for 100% centralized cloud management of the whole network from different sites to be controlled from a single user interface.

Features

  • 10G Lightning-Fast Uplink – 4× 10 Gbps SFP+ slots enable high-bandwidth connectivity and non-blocking switching capacity.
  • Gigabit Speeds – 24× gigabit RJ45 ports offer high-speed and reliable connections to other switches and devices.
  • Integrated into Omada SDN – Zero-Touch Provisioning (ZTP)*, Centralized Cloud Management, and Intelligent Monitoring.
  • Centralized Management – Cloud access and Omada app for ultra convenience and easy management.
  • Static Routing – Helps route internal traffic for more efficient use of network resources.
  • Robust Security Strategies – IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm control, DHCP Snooping, 802.1X, Radius Authentication, and more.
  • Optimize Voice and Video Applications – L2/L3/L4 QoS and IGMP snooping.
  • Standalone Management – Web, CLI (Console Port, Telnet, SSH), SNMP, RMON, and Dual Image bring powerful management capabilities

Specifications

Interface
  • 24 10/100/1000Mbps RJ45 Ports
  • 4 10GE SFP+ Slots
Console 1 RJ45 Console Port, 1 Micro-USB Console Port
Switching Capacity 128 Gbps
Packet Forwarding Rate 95.23 Mpps
MAC Address Table 16K
Packet Buffer 12 Mbit
Number of IP Interfaces 16
Number of Static Routers 48 (IPv4, IPv6)
Jumbo Frame 9 KB
Power Supply 100-240 V AC~50/60 Hz
Max Power Consumption 23.6 W (110V/60Hz)
Max Heat Dissipation 80.52 BTU/h (110 V/60 Hz)
Dimensions (W x D x H) 440 × 180 × 44 mm
Fan Quantity Fanless
Installation Desktop or Rack Mountable
Operating Temperature 0 °C to 45 °C
Storage Temperature -40 °C to 70 °C
Operation Humidity 10% to 90% RH, non-condensing
Storage Humidity 5% to 90% RH, non-condensing
Certification CE, FCC, RoHS
